This document describes how to use the public PV_Live Web API (v4) and gives example API queries. The API is under active development and so both the query and/or the data it provides may be subject to change.

The API provides PV outturn estimates at three levels of geographical resolution: nationally-aggregated, regionally-aggregated by DNO Licence Area (a.k.a "PES" region) and regionally-aggregated by Grid Supply Point (GSP).

DNO Licence Areas, also known as Public Electricity Supplier (PES) regions or GSP Group Regions, represent the approximate geographical areas served by 6 Distribution Network Operators who own and operate the GB electricity distribution network. GIS definitions for the DNO Licence Areas can be found on National Grid ESO’s Data Portal^[1]. In the PV_Live API, we use the acronym PES for convenience.

Grid Supply Points (GSPs) represent the interface between the transmission network and the distribution network. The geographical boundaries associated with GSPs can be found on the ESo Data Portal^[2].

The public API offers no guarantee with regards to availability and resilience and as such should always be supported by a more resilient, high-availability fall-back process. The API is optimised for transfer of data between Sheffield Solar servers and user applications using JSON by default (with an option for CSV). Some browsers (e.g. Mozilla Firefox) can pretty-print the json for human viewing.

Compression

The API compresses the response if:

The uncompressed response is >=500 bytes and
The request headers indicate that the client can handle compression.

We strongly recommend using compression, especially for larger responses. To configure your client to request compressed responses, add a request header. Here’s an example using the Python Requests library:

requests.get(url, headers={'Content-Type': 'application/json',

'Accept': 'application/json',

'Accept-Encoding': 'gzip, deflate',})

Throttling

To provide a reliable service we limit server load and mitigate the impact of Denial of Service (DoS) and Distributed DoS (DDos) attacks by throttling API requests. To support multiple requests (e.g. for several regions) we throttle to a maximum number of requests per half hour.

Timeout

To provide a reliable service we limit server load and mitigate the impact of Denial of Service (DoS) and Distributed DoS (DDos) attacks by enforcing a timeout on API requests (30s at 2024-12-06).

API Endpoints

PV_Live Outturn Estimates

Nationally Aggregated

Grid-connected PV generation in GB. This endpoint takes the form:

.../pvlive/api/v4/gsp/0?param1=<value1>&<param2>=<value2>

Aggregated by PES region

Grid-connected PV generation in GB aggregated by PES region. This endpoint takes the form:

.../pvlive/api/v4/pes/<pes_id>?<param1>=<value1>&<param2>=<value2>

Aggregated by GSP region

Grid-connected PV generation in GB aggregated by GSP region. This endpoint takes the form:

.../pvlive/api/v4/gsp/<gsp_id>?<param1>=<value1>&<param2>=<value2>

Request Parameters

All request parameters are lower case:

start=yyyy-mm-ddTHH:MM:SSZ GMT

Start of period (response gives readings at or after this time)
ISO8601 format (OK to replace T by space and/or to omit Z)
Default: end - 24h (24 hours before end)

end=yyyy-mm-ddTHH:MM:SSZ GMT

End of period (response gives readings at or before this time)
ISO8601 format (OK to replace T by space and/or to omit Z)
Default: now (current time)

data_format=json|csv

=json: (default) response will be an object containing data and metadata
=csv: single header row. Data rows, one per line

extra_fields=<field0>,<field1>,<field2>,...

Specify extra response fields in lower case, see full list of options below
e.g. extra_fields=capacity_mwp,installedcapacity_mwp

period=30|5

Desired temporal resolution (in minutes) for PV outturn estimates. Default is 30.

updated_gmt_from=yyyy-mm-ddTHH:MM:SSZ GMT
updated_gmt_to=yyyy-mm-ddTHH:MM:SSZ GMT

Uptime_gmt_from uptime_gmt_to

The web request options:

updated_gmt_from
updated_gmt_to

provide an additional filter for the response data returned from an API query.

Example

The following query returns national outturn between start and end

https://api.pvlive.uk/pvlive/api/v4/gsp/0?start=2024-12-15&end=2024-12-17

The following query returns national outturn between start and end which has been updated between updated_gmt_from and updated_gmt_to:

https://api.pvlive.uk/pvlive/api/v4/gsp/0?start=2024-12-15&end=2024-12-17&updated_gmt_from=2024-12-16T12&updated_gmt_to=2024-12-16T16

The start and end logic remains unchanged:

Start and end given: limit start to 366 days before end
Start alone given set end to start + 1 day
End alone given: set start to end - 1 day
Neither start nor end given: return the latest single row.
Limit end to at or before now

Extra fields

All lower case.

bias_error	Estimate of the Mean Normalised Bias Error (MnBE) on the modelled yield, calculated using K-fold cross validation (%)
capacity_mwp	Estimate of total effective PV capacity for the region including estimated performance degradation (Megawatt-peak).
installedcapacity_mwp	Estimate of total installed PV capacity (Megawatt-peak)
lcl_mw	Lower Confidence Limit, 90% probability that the actual PV generation is between LCL and UCL (Megawatts)
stats_error	Estimate of the Mean Absolute Percent Error (MAPE) on the modelled yield, calculated using K-fold cross validation (%)
ucl_mw	Upper Confidence Limit, 90% probability that the actual PV generation is between LCL and UCL (Megawatts).
uncertainty_MW	Estimate of the Root Mean Square Error (RMSE) on the modelled yield multiplied by the effective capacity, calculated using K-fold cross validation (Megawatts)
site_count	Number of sites used in derivation
updated_gmt	Timestamp of the latest update to the outturn estimate in ISO8601 format (GMT/UTC). Useful to check for retrospective revisions. (NOTE: updated_gmt as an extra field adds this column to the response. The request parameters: updated_gmt_from and updated_gmt_to (see above) provide an additional filter on the records returned.

Response

The default response is a JSON Object^[3] with two keys: data and metadata.

The value of the data key is an array of tuples, with each tuple giving the outturn estimate for a particular interval.

The value for the metadata key is an array of field-names, corresponding (in order) to the data e.g.

{

"data":[[1,"2019-01-01T00:00:00Z",1,0.0,332.42415,343.97426], ...]],

"meta":["pes_id","datetime_gmt","generation_mw"]

}

We strongly recommend using JSON libraries to extract the data. This avoids dependencies on the format (especially whitespace) in the response.

Response Fields

Default fields

The response will include the following fields, plus any extra fields specified with the extra_fields parameter:

pes_id/gsp_id	Unique integer ID for the PES/GSP region of interest (int). Note we add pes_id/gsp_id 0 as a proxy for nationally aggregated.
datetime_gmt	Outturn is for the period ending at this (GMT) timestamp
generation_mw	The average PV power estimate for the period (MegaWatts)

Example request

https://api.solar.sheffield.ac.uk/pvlive/api/v4/pes/10?start=2019-01-01T12:00:00&end=2019-01-01T13:00:00&data_format=csv

Example response

pes_id,datetime_gmt,generation_mw

10,2019-01-01T12:00:00Z,219.57995299999993

10,2019-01-01T12:30:00Z,239.79673999999997

10,2019-01-01T13:00:00Z,209.40142

Default Behaviours

The request start and end parameters determine the response data. The response is determined by the first matching condition in this table:

Request Parameters	Response Data
Neither start nor end given	Latest (national or single PES/GSP region)
Both start and end given	Outturns between start and end
Start given (end not given)	Outturns between start and (start + 24h)
End given (start not given)	Outturns between (end - 24h) and end

PES Region List

A list of PES regions. This list gives the pes_id used elsewhere along with the more commonly used string identifiers (e.g. “_A”) and the descriptive names for the regions (e.g. “WPD (East Midlands)”).

This endpoint takes the form:

.../pvlive/api/v4/pes_list?<param1>=<value1>&<param2>=<value2>

Request Parameters

data_format=json|csv

Specify the preferred return format for the data. Default is json.

Response Fields

pes_id	Unique integer ID for the PES region of interest (int). Note we add pes_id 0 as a proxy for nationally aggregated.
pes_name	String identifiers for the regions (e.g. “_A”).
pes_longname	Descriptive long name for each region.

Example request

https://api.solar.sheffield.ac.uk/pvlive/api/v4/pes_list

Example response

{

"data":[[0,"_0","NATIONAL"],[10,"_A","UKPN (East)"],[11,"_B","WPD (East Midlands)"],...,[23,"_M","NPG (Yorkshire Electric)"]],

"Meta":["pes_id","pes_name","pes_longname"]

}

GSP Region List

A list of GSP regions. This list gives the gsp_id used elsewhere along with the more commonly used string identifiers (e.g. “ABHA1”) and the pes_id denoted the DNO Licence Area which the GSP serves.

This endpoint takes the form:

.../pvlive/api/v4/gsp_list?<param1>=<value1>&<param2>=<value2>

Request Parameters

data_format=json|csv

Specify the preferred return format for the data. Default is json.

Response Fields

gsp_id	Unique integer ID for the GSP region of interest (int). Note we add gsp_id 0 as a proxy for nationally aggregated.
gsp_name	String identifiers for the regions (e.g. “ABHA1”). Note that some GSPs have been grouped together because it was not possible to discern which geographical regions they each serve. In these cases, the gsp_name field will be a pipe-separated list of names (e.g. “RAVE\|WISH”). The maximum length is 34 characters.
pes_id	Unique integer ID for the GSP Group Region to which the GSP belongs (e.g. 10).

Example request

https://api.solar.sheffield.ac.uk/pvlive/api/v4/gsp_list

Example response

{

"data":[[0,"NATIONAL",0],[1,"ABHA1",22],[2,"ABNE_P",17],…,[317,"WYMOM_1",10]],

"meta":["gsp_id","gsp_name","pes_id"]}

PES and GSP Region Shapes

Previous versions of this API have provided an endpoint for accessing the GIS definitions of the boundaries associated with PES and GSP regions. These endpoints are no longer supported. Instead, users should refer to the GIS boundary definitions hosted on National Grid ESO’s Data Portal:

GIS boundaries for GB DNO Licence Areas

https://data.nationalgrideso.com/system/gis-boundaries-for-gb-dno-license-areas

GIS boundaries for GB Grid Supply Points

https://data.nationalgrideso.com/system/gis-boundaries-for-gb-grid-supply-points

PV_Live outturn data will maintain compatibility with these definitions. The ESO Data Portal provides its own API interface for accessing the GIS definitions programmatically.

Note that as of 19th July 2022, the PV_Live regionally-aggregated outturns by GSP will use the 20220314 GSP boundary definitions

Querying the API

You can query the PV_Live API using:

Web browser: Chrome, Firefox, Internet Explorer etc.
Command line: curl, wget etc.
Python (we recommend the Python Requests and JSON libraries)
Most other programming languages

Web Browser

Querying the API from a web browser (Firefox, Chrome etc) may be useful for development and debugging.

The default response is in JSON with HTTP header:

Content-Type: application/json

Some browsers (Firefox and Chrome with plugin) recognise json and provide options for display.

Example requests

https://api.solar.sheffield.ac.uk/pvlive/api/v4

https://api.solar.sheffield.ac.uk/pvlive/api/v4?data_format=csv

UNIX Command Line

$ curl https://api.solar.sheffield.ac.uk/pvlive/api/v4

$ wget https://api.solar.sheffield.ac.uk/pvlive/api/v4

Python

Sheffield Solar is maintaining an open source Python library for interfacing with the PV_Live API, hosted on GitHub: https://github.com/SheffieldSolar/PV_Live-API

Error Codes

https://api.solar.sheffield.ac.uk/pvlive/api/vXXX

404 Not Found

https://api.solar.sheffield.ac.uk/pvlive/api/v4?XXX=YYY

No error: ignores unknown parameters

https://api.solar.sheffield.ac.uk/pvlive/api/v4/pes/XXX

No error: ignores unknown values in known parameters

https://api.solar.sheffield.ac.uk/pvlive/api/v4?data_format=XXX

Unknown format value . Expected json or csv

Data Formats Additional Information

PV_Live Outturn Estimates

Request

Request Parameter	Additional Information
start=yyyy-mm-ddTHH:MM:SSZ	ISO8601 format in GMT timezone. Several other formats may be accepted but with undefined behaviour. Response gives readings whose end-of-interval timestamps fall at or after this time. Default: end - 24h (24 hours before end)
end=yyyy-mm-ddTHH:MM:SSZ	ISO8601 format in GMT timezone. Several other formats may be accepted but with undefined behaviour. Response gives readings whose end-of-interval timestamps fall at or before this time. Default: now (current time)
data_format=csv	Data will be returned in Comma-Separated-Variable format with a single header row and one row per interval.
data_format=json	Data will be returned in minified JSON format.
extra_fields=<field0>,<field1>,<field2>,...	Extra fields are case sensitive in the request. Unrecognised field names will result in an error message from the server.

Response

Default fields

Field Name	Description	Unit / Format	Data Type
datetime_gmt	Result is for the interval ending at this timestamp	ISO8601 yyyy-mm-ddTHH:MM:SSZ (GMT)	string
generation_mw	The average PV power estimate for interval	MegaWatts	float

Extra Fields

Field Name	Description	Unit / Format	Data Type
lcl_mw	Lower Confidence Limit, 90% probability that the actual PV generation is between LCL and UCL.	MegaWatts	float
ucl_mw	Upper Confidence Limit, 90% probability that the actual PV generation is between LCL and UCL.	MegaWatts	float
capacity_mwp	Estimate of total effective PV capacity for the region including estimated performance degradation (MegaWatt-peak).	MegaWatts	float
installedcapacity_mwp	Estimate of total installed PV capacity (MegaWatt-peak)	MegaWatts	float

FAQ

Historical Data

2025-01-07

Can historical data be fetched using the live API?

If yes, up to how many years back can we retrieve the historical data from it?

For instance, will it contain the data of the last seven years?

Yes. The API serves historical data.

From 2010-01-01 to present.

However to reduce the risk of (Distributed) Denial of Service (DDOS) attack responses have a timeout (currently, 2025-01-05, 30s).

Pagination of Records

2025-01-07

Does the Sheffield Solar API support pagination of records?

No.

Record Limit

2025-01-07

Is there any upper limit on the number of records that can be pulled by this API?

If yes, how can we retrieve the records beyond that limit please?

No. There is no upper limit on the number of records.

However to reduce the risk of (Distributed) Denial of Service (DDOS) attack responses have a timeout (currently, 2025-01-05, 30s).

We provide a dedicated bulk download API endpoint for partner organisations (e.g. NESO). Users in partner organisations may email us for details of this.

Updated: Wed Jan 08 2025 14:51:44 GMT+0000 (Greenwich Mean Time)
